Technologie
Technische Übersicht
Rahmenset
Rahmen:
Fourstroke 01 Premium Carbon with Autodrop Technology | APS Suspension System | 100mm Travel | Fully Guided Internal Cable Routing | Post Mount Disc | 12 x 148mm Boost Thru-Axle
Gabel:
RockShox SID Ultimate
Federung
Federgabel:
RockShox SID Ultimate
Dämpfer:
RockShox SIDLUXE Ultimate
Lockout:
Full Sprint Lockout
Cockpit
Vorbau:
BMC MSM 01
Lenker:
BMC MFB 01 Carbon | 760mm
Sattel
Sattelstütze:
BMC Autodrop Integrated Dropper Seatpost | 80mm Drop
Sattel:
Prologo Dimension NDR
Antrieb
Kurbel:
SRAM X0 Eagle
Kettenblätter:
34T
Kassette:
SRAM X0 Eagle Transmission XS-1295
Kassettengrösse:
10-52T
Kette:
SRAM XX SL Eagle Transmission Flattop
Schaltwerk:
SRAM X0 Eagle Transmission
Schalthebel:
SRAM AXS Pod Controller
Übersetzung:
1 x 12
Tretlager:
PF92 Bottom Bracket
Bremsen
Bremshebel:
SRAM Level Ultimate
Bremsscheiben:
SRAM HS2
Bremsscheibengrösse (V/H):
160 / 160 S-M | 180 / 160 L-XL
Räder
Felgen:
DT Swiss XRC 1501 | 30mm Inner Width
Naben (V/H):
DT Swiss 240 Straightpull | Ratchet EXP 36
Bereifung:
Vittoria Mezcal | 2.35"
Tubeless-Informationen:
Tubeless Ready Rims | Tubetype Tires
Weitere Informationen
Reifenfreiheit:
62mm
ASTM-Klassifizierung:
Level 3
Maximales Systemgewicht:
110kg
Size | S | M | L | XL |
---|---|---|---|---|
Rider Height | <172 | 172-182 | 180-188 | >188 |
Reach | 437 | 457 | 477 | 500 |
Stack | 584 | 592 | 600 | 615 |
Bar Rise | 4 | 4 | 4 | 4 |
Bar Sweep | 8 | 8 | 8 | 8 |
Bar Width | 760 | 760 | 760 | 760 |
BB Drop | 53 | 53 | 53 | 53 |
Crank Length | 170 | 170 | 175 | 175 |
Fork Length | 513 | 513 | 513 | 513 |
Fork Rake | 44 | 44 | 44 | 44 |
Front Center | 714 | 738 | 762 | 791 |
Head Tube | 83.84 | 93.5 | 101.25 | 117.58 |
Head Tube Angle | 66.5 | 66.5 | 66.5 | 66.5 |
Rear Center | 432 | 432 | 432 | 432 |
Seat Angle | 76.7 | 76.7 | 76.7 | 76.7 |
Seat Tube | 420 | 440 | 470 | 510 |
Seatpost Drop | 80 | 80 | 80 | 80 |
Standover Height | 725 | 725 | 725 | 725 |
Stem Angle | -5 | -5 | -5 | -5 |
Stem Length | 50 | 60 | 60 | 70 |
Top Tube | 574 | 597 | 621.2 | 649.23 |
Trail | 113 | 113 | 113 | 113 |
Wheelbase | 1139 | 1171 | 1188 | 1218 |
