Technische Übersicht
Rahmenset
Rahmen:
Speedfox 01 - Advanced Pivot System - Trailsync | 01 Premium Carbon (F&R) - Internal cable management
Gabel:
01 Premium Carbon (F&R) | Internal cable management
Cockpit
Lenker:
BMC MRB 02 | 760mm
Vorbau:
BMC AMSM 02
Sattel
Sattelstütze:
BMC Trailsync
Sattel:
WTB Volt Team Ti
Antrieb
Übersetzung:
1 x 12
Kurbel:
SRAM X01 Eagle 34T
Kassette:
SRAM XG 1295 10-50T
Kette:
SRAM X01 Eagle Black
Schaltwerk:
SRAM X01 Eagle
Schalthebel:
SRAM X01 Eagle
Bremsen
Bremshebel:
SRAM Guide Ultimate (180/180)
Räder
Felgen:
DT Swiss XM 1501 Spline ONE 30
Naben (V/H):
DT Swiss XM 1501 Spline ONE | Centerlock
Bereifung:
Maxxis Forekaster ExO | 27,5 or 29 x 2.35
Weitere Informationen
Produktsicherheitsverordnung (GPSR):
Sicherheitshinweise GPSR (EU)
Verantwortliche Person gemäss GPSR (EU)
| Size | S | M |
|---|---|---|
| Rider Height | ||
| Reach | 413 | 436 |
| Stack | 584 | 595 |
| Bar Drop | ||
| Bar Reach | ||
| Bar Rise | 15 | 15 |
| Bar Sweep | 9 | 9 |
| Bar Width | 760 | 760 |
| Base Bar Drop Flat Cockpit | ||
| Base Bar Drop V-Cockpit | ||
| Base Bar Reach Flat Cockpit | ||
| Base Bar Reach V-Cockpit | ||
| BB Drop | 22 | 22 |
| BB Drop (SLACK) | ||
| BB Drop (STEEP) | ||
| BB Height (SLACK) | ||
| BB Height (STEEP) | ||
| Chainstay | ||
| Crank Length | 170 | 175 |
| LT | BB Drop (SLACK) | ||
| LT | BB Drop (STEEP) | ||
| LT | BB Height (SLACK) | ||
| LT | BB Height (STEEP) | ||
| LT | Chainstay | ||
| LT | Fork Length | ||
| LT | Fork Rake | ||
| LT | Frame Size | ||
| LT | Front Center (SLACK) | ||
| LT | Front Center (STEEP) | ||
| LT | Head Tube | ||
| LT | HT Angle (SLACK) | ||
| LT | HT Angle (STEEP) | ||
| LT | Reach (SLACK) | ||
| LT | Reach (STEEP) | ||
| LT | Rider Height | ||
| LT | Seat Tube | ||
| LT | ST Angle @750mm Saddle Height (SLACK) | ||
| LT | ST Angle @750mm Saddle Height (STEEP) | ||
| LT | ST Angle Actual (SLACK) | ||
| LT | ST Angle Actual (STEEP) | ||
| LT | ST Angle Effective (SLACK) | ||
| LT | ST Angle Effective (STEEP) | ||
| LT | Stack (SLACK) | ||
| LT | Stack (STEEP) | ||
| LT | Stand Over Height (80 in Front of BB) | ||
| LT | Stand Over Height (Lowest Point) | ||
| LT | Top Tube (SLACK) | ||
| LT | Top Tube (STEEP) | ||
| LT | Wheelbase (SLACK) | ||
| LT | Wheelbase (STEEP) | ||
| ST | BB Drop (SLACK) | ||
| ST | BB Drop (STEEP) | ||
| ST | BB Height (STACK) | ||
| ST | BB Height (STEEP) | ||
| ST | Chainstay | ||
| ST | Fork Length | ||
| ST | Fork Rake | ||
| ST | Frame Size | ||
| ST | Front Center (SLACK) | ||
| ST | Front Center (STEEP) | ||
| ST | Head Tube | ||
| ST | HT Angle (SLACK) | ||
| ST | HT Angle (STEEP) | ||
| ST | Reach (SLACK) | ||
| ST | Reach (STEEP) | ||
| ST | Rider Height | ||
| ST | Seat Tube | ||
| ST | ST Angle @750mm Saddle Height (SLACK) | ||
| ST | ST Angle @750mm Saddle Height (STEEP) | ||
| ST | ST Angle Actual (SLACK) | ||
| ST | ST Angle Actual (STEEP) | ||
| ST | ST Angle Effective (SLACK) | ||
| ST | ST Angle Effective (STEEP) | ||
| ST | Stack (SLACK) | ||
| ST | Stack (STEEP) | ||
| ST | Stand Over Height (80 in Front of BB) | ||
| ST | Stand Over Height (Lowest Point) | ||
| ST | Top Tube (SLACK) | ||
| ST | Top Tube (STEEP) | ||
| ST | Wheelbase (SLACK) | ||
| ST | Wheelbase (STEEP) | ||
| Fork Length | 517 | 517 |
| Fork Rake | 46 | 46 |
| Frame Size | ||
| Front Center | 685 | 712 |
| Front Center (SLACK) | ||
| Front Center (STEEP) | ||
| Head Tube | 110 | 120 |
| Head Tube Angle | 67.5 | 67.5 |
| HT Angle (SLACK) | ||
| HT Angle (STEEP) | ||
| Pad Reach Flat Cockpit | ||
| Pad Reach V-Cockpit | ||
| Pad Stack Flat Cockpit | ||
| Pad Stack V-Cockpit | ||
| Reach (SLACK) | ||
| Reach (STEEP) | ||
| Rear Center | 430 | 430 |
| Saddle Height Range | ||
| Seat Angle | 73.25 | 73.25 |
| Seat Tube | 410 | 430 |
| Seatpost Drop | ||
| Seatpost Length | ||
| Seatpost Offset | ||
| ST Angle @750mm Saddle Height (SLACK) | ||
| ST Angle @750mm Saddle Height (STEEP) | ||
| ST Angle Actual (SLACK) | ||
| ST Angle Actual (STEEP) | ||
| ST Angle Effective (SLACK) | ||
| ST Angle Effective (STEEP) | ||
| Stack (SLACK) | ||
| Stack (STEEP) | ||
| Stand Over Height (80 in Front of BB) | ||
| Stand Over Height (Lowest Point) | ||
| Standover Height | ||
| Stem Angle | ||
| Stem Length | 45 | 55 |
| Top Tube | 587 | 613 |
| Top Tube (SLACK) | ||
| Top Tube (STEEP) | ||
| Trail | 98 | 98 |
| Wheelbase | 1111 | 1138 |
| Wheelbase (SLACK) | ||
| Wheelbase (STEEP) |
