Reinforce your racing game with the Teammachine SLR. Discover the benchmark of cycling innovation with a road bike that defines performance for the modern era. Crafted from lightweight Premium Carbon, the TCC Race-engineered compliance and D-Shaped Carbon seatpost, deliver the hallmark BMC ride feel. Offering, precise handling, enduring comfort and of course speed, this racing bike uses everything we've learnt in over a decade of relentless development. Enhanced with features like Aerocore bottle cage design, ICS cable integration, and Stealth dropouts, every detail is optimized for peak performance.
Technology
Accelerated Composites Evolution Technology + (ACE+)
True BMC Ride Feel
Aerocore and ICS
Comfort is Speed
Technical Overview
Frameset
Frame:
Teammachine SLR Carbon with Aerocore Design | ICS Technology Stealth Cable Routing | Stealth Dropout Design | TCC Race compliance level | Flat Mount Disc | 12 x 142mm Thru-Axle | Optimized for Aerocore Bottle Cages
Fork:
Teammachine SLR Carbon | ICS Technology Stealth Cable Routing | TCC Race Compliance Level | Stealth Dropout Design | Flat Mount Disc | 12 x 100mm Thru-Axle | 48mm offset Size 47-51 | 43mm offset Size 54-61
Cockpit
Stem:
BMC RSM 01 | Integrated Cockpit System Technology
Handlebar:
BMC HB D4 03, 0, 6 | Alloy 6061 | Race Geometry | 135mm drop, 70mm reach, 6° flare
Seat
Seatpost:
Teammachine SLR Carbon D-Shaped Seatpost | 15mm Offset
Saddle:
Fizik Antares R7 | S-Alloy rail 140mm [or] Selle Italia Model X Superflow | FeC Alloy rail | 145mm
Drivetrain
Crankset:
SHIMANO 105 (FC-R7100)
Chainrings:
50-34T
Cassette:
SHIMANO 105 (CS-R7101)
Cassette Size:
11-34T
Chain:
SHIMANO CN-M6100
Front Derailleur:
SHIMANO 105 Di2 (FD-R7150)
Rear Derailleur:
SHIMANO 105 Di2 (RD-R7150)
Shifters:
SHIMANO 105 Di2 (ST-R7170)
Gears:
2 x 12
Bottom Bracket:
SHIMANO Press-Fit Bottom Bracket (BB-RS500-PB)
Brakes
Brake Levers / Calipers:
SHIMANO 105 (BR-R7170)
Rotors:
SHIMANO SM-RT70 | Centerlock
Rotor Size (F/R):
160 / 160mm
Wheels
Rims:
PRD23 | 23mm
Hubs (F/R):
SHIMANO HB-TC500-12 & FH-TC500-HL | Center Lock| 28H
Tires:
Pirelli P Zero Road | 26mm
Tubeless Information:
Non-Tubeless Rims | Non-Tubeless Clincher Tire
Additional Information
Tire Clearance:
30mm measured tire
Weight without Pedals:
8.3kg | Size 54 as pictured with all accessories
ASTM Classification:
Level 1
System Weight Limit:
110kg
General Product Safety Regulation (GPSR):
Safety Instructions GPSR (EU)
Responsible person according to GPSR (EU)
| Size | 47 | 51 | 54 | 56 | 58 | 61 |
|---|---|---|---|---|---|---|
| Rider Height | <166 | 166-174 | 172-180 | 178-186 | 184-192 | >190 |
| Reach | 367 | 377 | 386 | 392 | 401 | 409 |
| Stack | 506 | 530 | 550 | 565 | 584 | 608 |
| Bar Drop | 135 | 135 | 135 | 135 | 135 | 135 |
| Bar Reach | 70 | 70 | 70 | 70 | 70 | 70 |
| Bar Width | 390/414 | 390/414 | 390/414 | 410/434 | 410/434 | 430/454 |
| BB Drop | 69 | 69 | 69 | 69 | 69 | 69 |
| Crank Length | 170 | 170 | 172.5 | 172.5 | 175 | 175 |
| Fork Length | 368 | 368 | 368 | 368 | 368 | 368 |
| Fork Rake | 48 | 48 | 43 | 43 | 43 | 43 |
| Front Center | 568 | 586 | 589 | 599 | 614 | 630 |
| Head Tube | 110 | 130 | 145 | 165 | 184 | 210 |
| Head Tube Angle | 71.5° | 71.5° | 72.3° | 72.3° | 72.3° | 72.3° |
| Rear Center | 410 | 410 | 410 | 410 | 410 | 410 |
| Seat Angle | 73.5° | 73.5° | 73.5° | 73.5° | 73.5° | 73.5° |
| Seat Tube | 423 | 468 | 504 | 524 | 545 | 574 |
| Seatpost Length | 330 | 380 | 380 | 380 | 380 | 380 |
| Seatpost Offset | 15 | 15 | 15 | 15 | 15 | 15 |
| Standover Height | 717 | 752 | 779 | 797 | 817 | 843 |
| Stem Angle | -8 | -8 | -8 | -8 | -8 | -8 |
| Stem Length | 90 | 100 | 100 | 110 | 110 | 120 |
| Top Tube | 517 | 534 | 549 | 559 | 574 | 589 |
| Trail | 63 | 63 | 63 | 63 | 63 | 63 |
| Wheelbase | 968 | 986 | 989 | 1000 | 1015 | 1030 |
