Technology
Technical Overview
Frameset
Frame:
Roadmachine Premium Carbon with Tuned Compliance Concept Endurance | Internal Cable Routing | Flat Mount Disc | 12 x 142mm Thru-Axle
Fork:
Roadmachine Premium Carbon with Tuned Compliance Concept Endurance | Internal Cable Routing | Flat Mount Disc | 12 x 100mm Thru-Axle
Cockpit
Stem:
BMC RSM 01
Handlebar:
BMC RAB 03 | Ergo Top Shape | Compact Bend
Seat
Seatpost:
Roadmachine Premium Carbon D-Shaped Seatpost
Saddle:
Fizik Antares R7
Brakes
Brake Levers / Calipers:
SHIMANO 105 (BR-R7170)
Rotors:
SHIMANO SM-RT70
Rotor Size (F/R):
160 / 140mm
Wheels
Rims:
Mavic Open Disc
Hubs (F/R):
CL-712 (F) | RXC-1425 (R) | Thru-Axle
Tires:
Vittoria Rubino | 28mm
Additional Information
Tire Clearance:
33mm
ASTM Classification:
Level 2
System Weight Limit:
110kg
Size | 47 | 51 | 54 | 56 | 58 | 61 |
---|---|---|---|---|---|---|
Rider Height | <166 | 166-174 | 172-180 | 178-186 | 184-192 | >190 |
Reach | 374 | 382 | 386 | 390 | 394 | 398 |
Stack | 516 | 541 | 562 | 586 | 610 | 644 |
Bar Drop | 125 | 125 | 125 | 125 | 125 | 125 |
Bar Reach | 70 | 70 | 70 | 70 | 70 | 70 |
Bar Width | 400 | 420 | 420 | 420 | 420 | 440 |
BB Drop | 71 | 71 | 71 | 71 | 71 | 71 |
Crank Length | 170 | 170 | 172.5 | 172.5 | 175 | 175 |
Fork Length | 375 | 375 | 375 | 375 | 375 | 375 |
Fork Rake | 50 | 50 | 45 | 45 | 45 | 45 |
Front Center | 583 | 599 | 597 | 609 | 621 | 635 |
Head Tube | 112 | 139 | 156 | 181 | 206 | 242 |
Head Tube Angle | 71.2 | 71.2 | 72 | 72 | 72 | 72 |
Rear Center | 410 | 410 | 410 | 410 | 410 | 410 |
Seat Angle | 74.2 | 74.2 | 74.2 | 74.2 | 74.2 | 74.2 |
Seat Tube | 420 | 457 | 500 | 522 | 539 | 573 |
Seatpost Length | 330 | 380 | 380 | 380 | 380 | 430 |
Seatpost Offset | 15 | 15 | 15 | 15 | 15 | 15 |
Standover Height | 719 | 750 | 782 | 805 | 825 | 859 |
Stem Angle | ±8 | ±8 | ±8 | ±8 | ±8 | ±8 |
Stem Length | 90 | 90 | 100 | 110 | 110 | 120 |
Top Tube | 522 | 532 | 546 | 556 | 568 | 583 |
Trail | 63 | 63 | 63 | 63 | 63 | 63 |
Wheelbase | 982 | 999 | 997 | 1008 | 1020 | 1035 |
