Descripción técnica
Cuadro
Cuadro:
Sportelite 27.5 | Al-13 Butted - Hydroformed aluminum
Cockpit
Manillar:
BMC MRB 03 | 700mm
Potencia:
BMC MSM 03
Tija de Sillín:
BMC MSP 03
Sillín:
Selle Royal Seta
Transmisión
Marchas:
2 x 10
Platos y Bielas:
Shimano SLX | 36-22T
Cassette:
Shimano CS-HG50 | 11-36T
Cadena:
KMC X-10
Desviador Delantero:
Shimano Deore
Cambio Trasero:
Shimano XT10
Manetas de Cambio:
Shimano Deore
Frenos
Pinzas de Freno:
Shimano Deore
Ruedas
Llantas:
Alex MD19
Bujes:
Shimano Deore
Neumáticos:
Continental Race King Performance | 2.2
| Size | XS | S | M | L | XL |
|---|---|---|---|---|---|
| Rider Height | |||||
| Reach | 385 | 400 | 415 | 435 | 455 |
| Stack | 585 | 594 | 604 | 618 | 632 |
| Bar Drop | |||||
| Bar Reach | |||||
| Bar Rise | 4 | 4 | 4 | 4 | 4 |
| Bar Sweep | 9 | 9 | 9 | 9 | 9 |
| Bar Width | 720 | 720 | 720 | 720 | 720 |
| Base Bar Drop Flat Cockpit | |||||
| Base Bar Drop V-Cockpit | |||||
| Base Bar Reach Flat Cockpit | |||||
| Base Bar Reach V-Cockpit | |||||
| BB Drop | 42 | 42 | 42 | 42 | 42 |
| BB Drop (SLACK) | |||||
| BB Drop (STEEP) | |||||
| BB Height (SLACK) | |||||
| BB Height (STEEP) | |||||
| Chainstay | |||||
| Crank Length | 170 | 170 | 175 | 175 | 175 |
| LT | BB Drop (SLACK) | |||||
| LT | BB Drop (STEEP) | |||||
| LT | BB Height (SLACK) | |||||
| LT | BB Height (STEEP) | |||||
| LT | Chainstay | |||||
| LT | Fork Length | |||||
| LT | Fork Rake | |||||
| LT | Frame Size | |||||
| LT | Front Center (SLACK) | |||||
| LT | Front Center (STEEP) | |||||
| LT | Head Tube | |||||
| LT | HT Angle (SLACK) | |||||
| LT | HT Angle (STEEP) | |||||
| LT | Reach (SLACK) | |||||
| LT | Reach (STEEP) | |||||
| LT | Rider Height | |||||
| LT | Seat Tube | |||||
| LT | ST Angle @750mm Saddle Height (SLACK) | |||||
| LT | ST Angle @750mm Saddle Height (STEEP) | |||||
| LT | ST Angle Actual (SLACK) | |||||
| LT | ST Angle Actual (STEEP) | |||||
| LT | ST Angle Effective (SLACK) | |||||
| LT | ST Angle Effective (STEEP) | |||||
| LT | Stack (SLACK) | |||||
| LT | Stack (STEEP) | |||||
| LT | Stand Over Height (80 in Front of BB) | |||||
| LT | Stand Over Height (Lowest Point) | |||||
| LT | Top Tube (SLACK) | |||||
| LT | Top Tube (STEEP) | |||||
| LT | Wheelbase (SLACK) | |||||
| LT | Wheelbase (STEEP) | |||||
| ST | BB Drop (SLACK) | |||||
| ST | BB Drop (STEEP) | |||||
| ST | BB Height (STACK) | |||||
| ST | BB Height (STEEP) | |||||
| ST | Chainstay | |||||
| ST | Fork Length | |||||
| ST | Fork Rake | |||||
| ST | Frame Size | |||||
| ST | Front Center (SLACK) | |||||
| ST | Front Center (STEEP) | |||||
| ST | Head Tube | |||||
| ST | HT Angle (SLACK) | |||||
| ST | HT Angle (STEEP) | |||||
| ST | Reach (SLACK) | |||||
| ST | Reach (STEEP) | |||||
| ST | Rider Height | |||||
| ST | Seat Tube | |||||
| ST | ST Angle @750mm Saddle Height (SLACK) | |||||
| ST | ST Angle @750mm Saddle Height (STEEP) | |||||
| ST | ST Angle Actual (SLACK) | |||||
| ST | ST Angle Actual (STEEP) | |||||
| ST | ST Angle Effective (SLACK) | |||||
| ST | ST Angle Effective (STEEP) | |||||
| ST | Stack (SLACK) | |||||
| ST | Stack (STEEP) | |||||
| ST | Stand Over Height (80 in Front of BB) | |||||
| ST | Stand Over Height (Lowest Point) | |||||
| ST | Top Tube (SLACK) | |||||
| ST | Top Tube (STEEP) | |||||
| ST | Wheelbase (SLACK) | |||||
| ST | Wheelbase (STEEP) | |||||
| Fork Length | 490 | 490 | 490 | 490 | 490 |
| Fork Rake | 42 | 42 | 42 | 42 | 42 |
| Frame Size | |||||
| Front Center | 628 | 646 | 665 | 690 | 715 |
| Front Center (SLACK) | |||||
| Front Center (STEEP) | |||||
| Head Tube | 100 | 110 | 120 | 140 | 150 |
| Head Tube Angle | 70 | 70 | 70 | 70 | 70 |
| HT Angle (SLACK) | |||||
| HT Angle (STEEP) | |||||
| Pad Reach Flat Cockpit | |||||
| Pad Reach V-Cockpit | |||||
| Pad Stack Flat Cockpit | |||||
| Pad Stack V-Cockpit | |||||
| Reach (SLACK) | |||||
| Reach (STEEP) | |||||
| Rear Center | 438 | 438 | 438 | 438 | 438 |
| Saddle Height Range | |||||
| Seat Angle | 73.75 | 73.5 | 73 | 73 | 72.5 |
| Seat Tube | 380 | 415 | 460 | 500 | 540 |
| Seatpost Drop | |||||
| Seatpost Length | 350 | 350 | 400 | 400 | 400 |
| Seatpost Offset | |||||
| ST Angle @750mm Saddle Height (SLACK) | |||||
| ST Angle @750mm Saddle Height (STEEP) | |||||
| ST Angle Actual (SLACK) | |||||
| ST Angle Actual (STEEP) | |||||
| ST Angle Effective (SLACK) | |||||
| ST Angle Effective (STEEP) | |||||
| Stack (SLACK) | |||||
| Stack (STEEP) | |||||
| Stand Over Height (80 in Front of BB) | |||||
| Stand Over Height (Lowest Point) | |||||
| Standover Height | |||||
| Stem Angle | 6 | 6 | 6 | 6 | 6 |
| Stem Length | 70 | 70 | 70 | 70 | 70 |
| Top Tube | 555 | 576 | 600 | 624 | 654 |
| Top Tube (SLACK) | |||||
| Top Tube (STEEP) | |||||
| Trail | 82 | 82 | 82 | 82 | 82 |
| Wheelbase | 1063 | 1081 | 1100 | 1125 | 1150 |
| Wheelbase (SLACK) | |||||
| Wheelbase (STEEP) |
