Panoramica tecnica
Telaio
Telaio:
iSC (Rear Travel 150mm) | Alloy Triple Butted - Hydroforming
Forcella:
Fox Talas RL O/B | 150-120mm
Cockpit
Piega:
Scor MKII | Low Rise
Attacco Manubrio:
Scor MKII
Reggisella:
Scor MKII
Sella:
Scor
Gruppo
Ingranaggi:
3 x 10
Guarnitura:
Shimano 552 | 42-32-24
Cassetta:
Shimano HG81 | 11-36
Deragliatore Anteriore:
Shimano XT
Deragliatore Posteriore:
Shimano XT
Comandi:
Shimano SLX
Freni
Leve Freno / Pinze:
Avid Elixir 5 Disc | 185mm Rotor F & R
Ruote
Cerchi:
Easton Vice
Mozzi:
Easton Vice
Pneumatici:
Schwalbe Nobby Nic | 26 x 2.25
Informazioni aggiuntive
Regolamento sulla sicurezza generale dei prodotti (GPSR):
Avvertenze di sicurezza GPSR (UE)
Persona responsabile ai sensi del GPSR (UE)
| Size | XS | S | M | L | XL |
|---|---|---|---|---|---|
| Rider Height | < 158 | 158-168 | 166-178 | 175-185 | > 185 |
| Reach | 383 | 404 | 426 | 444 | 476 |
| Stack | 549 | 563 | 572 | 595 | 613 |
| Bar Drop | |||||
| Bar Reach | |||||
| Bar Rise | |||||
| Bar Sweep | |||||
| Bar Width | 680 | 680 | 680 | 680 | 680 |
| Base Bar Drop Flat Cockpit | |||||
| Base Bar Drop V-Cockpit | |||||
| Base Bar Reach Flat Cockpit | |||||
| Base Bar Reach V-Cockpit | |||||
| BB Drop | -13 | -13 | -13 | -13 | -13 |
| BB Drop (SLACK) | |||||
| BB Drop (STEEP) | |||||
| BB Height (SLACK) | |||||
| BB Height (STEEP) | |||||
| Chainstay | |||||
| Crank Length | 170 | 170 | 175 | 175 | 175 |
| LT | BB Drop (SLACK) | |||||
| LT | BB Drop (STEEP) | |||||
| LT | BB Height (SLACK) | |||||
| LT | BB Height (STEEP) | |||||
| LT | Chainstay | |||||
| LT | Fork Length | |||||
| LT | Fork Rake | |||||
| LT | Frame Size | |||||
| LT | Front Center (SLACK) | |||||
| LT | Front Center (STEEP) | |||||
| LT | Head Tube | |||||
| LT | HT Angle (SLACK) | |||||
| LT | HT Angle (STEEP) | |||||
| LT | Reach (SLACK) | |||||
| LT | Reach (STEEP) | |||||
| LT | Rider Height | |||||
| LT | Seat Tube | |||||
| LT | ST Angle @750mm Saddle Height (SLACK) | |||||
| LT | ST Angle @750mm Saddle Height (STEEP) | |||||
| LT | ST Angle Actual (SLACK) | |||||
| LT | ST Angle Actual (STEEP) | |||||
| LT | ST Angle Effective (SLACK) | |||||
| LT | ST Angle Effective (STEEP) | |||||
| LT | Stack (SLACK) | |||||
| LT | Stack (STEEP) | |||||
| LT | Stand Over Height (80 in Front of BB) | |||||
| LT | Stand Over Height (Lowest Point) | |||||
| LT | Top Tube (SLACK) | |||||
| LT | Top Tube (STEEP) | |||||
| LT | Wheelbase (SLACK) | |||||
| LT | Wheelbase (STEEP) | |||||
| ST | BB Drop (SLACK) | |||||
| ST | BB Drop (STEEP) | |||||
| ST | BB Height (STACK) | |||||
| ST | BB Height (STEEP) | |||||
| ST | Chainstay | |||||
| ST | Fork Length | |||||
| ST | Fork Rake | |||||
| ST | Frame Size | |||||
| ST | Front Center (SLACK) | |||||
| ST | Front Center (STEEP) | |||||
| ST | Head Tube | |||||
| ST | HT Angle (SLACK) | |||||
| ST | HT Angle (STEEP) | |||||
| ST | Reach (SLACK) | |||||
| ST | Reach (STEEP) | |||||
| ST | Rider Height | |||||
| ST | Seat Tube | |||||
| ST | ST Angle @750mm Saddle Height (SLACK) | |||||
| ST | ST Angle @750mm Saddle Height (STEEP) | |||||
| ST | ST Angle Actual (SLACK) | |||||
| ST | ST Angle Actual (STEEP) | |||||
| ST | ST Angle Effective (SLACK) | |||||
| ST | ST Angle Effective (STEEP) | |||||
| ST | Stack (SLACK) | |||||
| ST | Stack (STEEP) | |||||
| ST | Stand Over Height (80 in Front of BB) | |||||
| ST | Stand Over Height (Lowest Point) | |||||
| ST | Top Tube (SLACK) | |||||
| ST | Top Tube (STEEP) | |||||
| ST | Wheelbase (SLACK) | |||||
| ST | Wheelbase (STEEP) | |||||
| Fork Length | |||||
| Fork Rake | |||||
| Frame Size | |||||
| Front Center | |||||
| Front Center (SLACK) | |||||
| Front Center (STEEP) | |||||
| Head Tube | 110 | 125 | 135 | 160 | 180 |
| Head Tube Angle | 66.5 | 66.5 | 66.5 | 66.5 | 66.5 |
| HT Angle (SLACK) | |||||
| HT Angle (STEEP) | |||||
| Pad Reach Flat Cockpit | |||||
| Pad Reach V-Cockpit | |||||
| Pad Stack Flat Cockpit | |||||
| Pad Stack V-Cockpit | |||||
| Reach (SLACK) | |||||
| Reach (STEEP) | |||||
| Rear Center | 430 | 430 | 430 | 430 | 430 |
| Saddle Height Range | |||||
| Seat Angle | 73.5 | 73.5 | 73.5 | 73.5 | 73.5 |
| Seat Tube | 420 | 420 | 460 | 495 | 530 |
| Seatpost Drop | |||||
| Seatpost Length | |||||
| Seatpost Offset | |||||
| ST Angle @750mm Saddle Height (SLACK) | |||||
| ST Angle @750mm Saddle Height (STEEP) | |||||
| ST Angle Actual (SLACK) | |||||
| ST Angle Actual (STEEP) | |||||
| ST Angle Effective (SLACK) | |||||
| ST Angle Effective (STEEP) | |||||
| Stack (SLACK) | |||||
| Stack (STEEP) | |||||
| Stand Over Height (80 in Front of BB) | |||||
| Stand Over Height (Lowest Point) | |||||
| Standover Height | |||||
| Stem Angle | |||||
| Stem Length | |||||
| Top Tube | 540 | 565 | 590 | 615 | 640 |
| Top Tube (SLACK) | |||||
| Top Tube (STEEP) | |||||
| Trail | |||||
| Wheelbase | |||||
| Wheelbase (SLACK) | |||||
| Wheelbase (STEEP) |
